10226-55F3PC
3M
3M
CONN RCPT 26POS R/A SOLDER
$0.00
Available to order
Reference Price (USD)
100+
$4.46000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
3M's 10226-55F3PC represents the gold standard in D-Shaped Centronics Connectors within the broader Connectors, Interconnects category. These components are characterized by their distinctive D-shell mechanical design that prevents incorrect mating and provides mechanical stability. Technical highlights include solder cup or PCB termination styles, operating temperatures from -40 C to +105 C, and current ratings up to 5A per contact. The primary application fields encompass data acquisition systems, military/aerospace electronics, and industrial control panels. Specific implementations include legacy server backplanes, robotic controller interfaces, and avionics test equipment where these connectors ensure fail-safe operation.
Specifications
- Product Status: Obsolete
- Connector Style: Outer Shroud Contacts
- Connector Type: Receptacle
- Number of Positions: 26
- Number of Rows: 2
- Mounting Type: Panel Mount, Through Hole, Right Angle
- Termination: Solder
- Flange Feature: Latchblocks
- Type: -
- Features: Board Lock, Shielded
- Contact Finish: Gold
- Contact Finish Thickness: 30.0µin (0.76µm)
