1446800000
Weidmüller
Weidmüller
CONN HEADER VERT 36POS 5MM
$58.85
Available to order
Reference Price (USD)
10+
$54.01200
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your interconnections with the 1446800000 rectangular connector header from Weidmüller. These male pin headers feature a rugged design for high-stress environments. Offering excellent electrical and mechanical properties, the 1446800000 is perfect for automotive, industrial, and consumer electronics. Weidmüller ensures each connector is tested for performance and durability.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.197" (5.00mm)
- Number of Positions: 36
- Number of Rows: 4
- Row Spacing - Mating: 0.197" (5.00mm)
- Number of Positions Loaded: All
- Style: Board to Board or Cable
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Latch Lock
- Contact Length - Mating: -
- Contact Length - Post: 0.126" (3.20mm)
- Overall Contact Length: -
- Insulation Height: 0.465" (11.80mm)
- Contact Shape: Circular
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: -
- Contact Material: Copper Alloy
- Insulation Material: Polyamide (PA), Nylon
- Features: Mounting Flange
- Operating Temperature: 100°C
- Ingress Protection: IP20
- Material Flammability Rating: UL94 V-0
- Insulation Color: Gray
- Current Rating (Amps): 10A
- Voltage Rating: 300V
