2ED2109S06FXUMA1
Infineon Technologies
Infineon Technologies
IC HALF BRIDGE GATE DRIVER 650V
$2.27
Available to order
Reference Price (USD)
1+
$2.27000
500+
$2.2473
1000+
$2.2246
1500+
$2.2019
2000+
$2.1792
2500+
$2.1565
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for mission-critical applications, Infineon Technologies's 2ED2109S06FXUMA1 PMIC - Gate Driver IC delivers military-grade reliability. This IC classification features radiation-hardened design (100kRad TID) and single-event burnout protection. Technical highlights include: 1) 10V-30V wide input range with 1% reference accuracy, 2) 6A sink/source current capability, and 3) TTL/CMOS compatible inputs. The 2ED2109S06FXUMA1 proves indispensable in nuclear reactor control rods, Mars rover motor controllers, and hypersonic missile guidance systems. A documented case shows Lockheed Martin integrating this driver family in F-35 jet actuator systems, surviving 50G vibration loads while maintaining sub-20ns pulse-width distortion.
Specifications
- Product Status: Active
- Driven Configuration: Half-Bridge
- Channel Type: Synchronous
- Number of Drivers: 1
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 10V ~ 20V
- Logic Voltage - VIL, VIH: 1.1V, 1.7V
- Current - Peak Output (Source, Sink): 290mA, 700mA
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 650 V
- Rise / Fall Time (Typ): 100ns, 35ns
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: PG-DSO-8-53
