2N5060RLRAG
onsemi
onsemi
SCR 30V 800MA TO92-3
$0.16
Available to order
Reference Price (USD)
1+
$0.16000
500+
$0.1584
1000+
$0.1568
1500+
$0.1552
2000+
$0.1536
2500+
$0.152
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Introducing the 2N5060RLRAG SCR by onsemi, a high-reliability component in the Thyristors family of Discrete Semiconductor Products. Its notable features include precise gate control and excellent thermal cycling performance. Widely adopted in traction systems, welding inverters, and power distribution networks, this thyristor demonstrates exceptional versatility. onsemi's 2N5060RLRAG is the smart choice for engineers seeking robust power control solutions.
Specifications
- Product Status: Obsolete
- Voltage - Off State: 30 V
- Voltage - Gate Trigger (Vgt) (Max): 800 mV
- Current - Gate Trigger (Igt) (Max): 200 µA
- Voltage - On State (Vtm) (Max): 1.7 V
- Current - On State (It (AV)) (Max): 510 mA
- Current - On State (It (RMS)) (Max): 800 mA
- Current - Hold (Ih) (Max): 5 mA
- Current - Off State (Max): 10 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 10A @ 60Hz
- SCR Type: Sensitive Gate
- Operating Temperature: -40°C ~ 110°C
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 Long Body (Formed Leads)
- Supplier Device Package: TO-92 (TO-226)
