349-10-122-00-560000
Mill-Max Manufacturing Corp.
Mill-Max Manufacturing Corp.
CONN HEADER SMD 22POS 2.54MM
$6.00
Available to order
Reference Price (USD)
1+
$4.86000
10+
$4.67000
25+
$4.28080
50+
$4.08600
100+
$3.89150
250+
$3.40508
500+
$3.30780
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your interconnections with the 349-10-122-00-560000 rectangular connector header from Mill-Max Manufacturing Corp.. These male pin headers feature a rugged design for high-stress environments. Offering excellent electrical and mechanical properties, the 349-10-122-00-560000 is perfect for automotive, industrial, and consumer electronics. Mill-Max Manufacturing Corp. ensures each connector is tested for performance and durability.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.100" (2.54mm)
- Number of Positions: 22
- Number of Rows: 1
- Row Spacing - Mating: -
- Number of Positions Loaded: All
- Style: Board to Board
- Shrouding: Unshrouded
- Mounting Type: Surface Mount
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Length - Mating: 0.136" (3.45mm)
- Contact Length - Post: -
- Overall Contact Length: -
- Insulation Height: 0.110" (2.79mm)
- Contact Shape: Circular
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 10.0µin (0.25µm)
- Contact Finish - Post: Gold
- Contact Material: -
- Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT)
- Features: -
- Operating Temperature: -
- Ingress Protection: -
- Material Flammability Rating: -
- Insulation Color: Black
- Current Rating (Amps): -
- Voltage Rating: -
