5228686-1
TE Connectivity AMP Connectors
TE Connectivity AMP Connectors
CONN TWINAX JACK R/A PCB
$13.84
Available to order
Reference Price (USD)
1+
$10.84000
10+
$10.37100
35+
$9.42800
70+
$8.95657
105+
$8.72086
280+
$7.77807
525+
$7.30667
1,015+
$6.45815
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 5228686-1 from TE Connectivity AMP Connectors is a high-performance RF coaxial connector designed for reliable signal transmission in demanding applications. As part of our premium Coaxial Connectors (RF) collection, this component features excellent impedance matching and low signal loss characteristics. These connectors boast superior shielding against EMI/RFI interference, ensuring clean signal transfer even in electrically noisy environments. The durable construction with gold-plated contacts provides long-term reliability with minimal insertion loss. Common applications include telecommunications infrastructure (5G base stations, microwave links), aerospace avionics systems, medical imaging equipment (MRI machines), and test & measurement instruments. The 5228686-1 is particularly suitable for high-frequency applications up to 18GHz, making it ideal for satellite communications and radar systems.
Specifications
- Product Status: Obsolete
- Connector Style: BNC, Twinaxial
- Connector Type: Jack, Female Socket and Male Pin
- Contact Termination: Solder
- Shield Termination: Solder
- Impedance: Non-Constant
- Mounting Type: Panel Mount, Through Hole, Right Angle
- Mounting Feature: Bulkhead - Front Side Nut
- Cable Group: -
- Fastening Type: Bayonet Lock
- Frequency - Max: -
- Number of Ports: 1
- Features: Board Guide, Isolated
- Housing Color: Natural, Silver
- Ingress Protection: -
- Center Contact Material: Brass; Phosphor Bronze
