6ED2230S12TXUMA1
Infineon Technologies
Infineon Technologies
1200V THREE PHASE DRIVER
$13.57
Available to order
Reference Price (USD)
1+
$13.57000
500+
$13.4343
1000+
$13.2986
1500+
$13.1629
2000+
$13.0272
2500+
$12.8915
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for mission-critical applications, Infineon Technologies's 6ED2230S12TXUMA1 PMIC - Gate Driver IC delivers military-grade reliability. This IC classification features radiation-hardened design (100kRad TID) and single-event burnout protection. Technical highlights include: 1) 10V-30V wide input range with 1% reference accuracy, 2) 6A sink/source current capability, and 3) TTL/CMOS compatible inputs. The 6ED2230S12TXUMA1 proves indispensable in nuclear reactor control rods, Mars rover motor controllers, and hypersonic missile guidance systems. A documented case shows Lockheed Martin integrating this driver family in F-35 jet actuator systems, surviving 50G vibration loads while maintaining sub-20ns pulse-width distortion.
Specifications
- Product Status: Active
- Driven Configuration: High-Side or Low-Side
- Channel Type: 3-Phase
- Number of Drivers: 6
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 10V ~ 20V
- Logic Voltage - VIL, VIH: 0.7V, 2.3V
- Current - Peak Output (Source, Sink): 350mA, 650mA
- Input Type: Inverting
- High Side Voltage - Max (Bootstrap): 1200 V
- Rise / Fall Time (Typ): 35ns, 20ns
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 28-SOIC (0.295", 7.50mm Width), 24 Leads
- Supplier Device Package: PG-DSO-24
