74AC11000NSR
Texas Instruments
Texas Instruments
IC GATE NAND 4CH 2-INP 16SO
$0.90
Available to order
Reference Price (USD)
1+
$0.90000
500+
$0.891
1000+
$0.882
1500+
$0.873
2000+
$0.864
2500+
$0.855
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Texas Instruments's 74AC11000NSR exemplifies innovation in Logic - Gates and Inverters technology. This high-speed CMOS logic IC combines multiple gate functions with exceptional noise margin characteristics. The device's wide operating voltage range (2V to 6V) accommodates diverse design requirements while maintaining consistent performance. Common uses include signal conditioning in medical devices, encoding/decoding circuits in security systems, and interface logic in automotive electronics. The 74AC11000NSR is particularly valuable in applications requiring precise timing control, such as industrial timers, digital clocks, and microcontroller reset circuits. Its industry-standard package options ensure easy PCB layout and manufacturing compatibility.
Specifications
- Product Status: Discontinued at Digi-Key
- Logic Type: NAND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: -
- Voltage - Supply: 3V ~ 5.5V
- Current - Quiescent (Max): 4 µA
- Current - Output High, Low: 24mA, 24mA
- Logic Level - Low: 0.9V ~ 1.65V
- Logic Level - High: 2.1V ~ 3.85V
- Max Propagation Delay @ V, Max CL: 6.5ns @ 5V, 50pF
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Supplier Device Package: 16-SO
- Package / Case: 16-SOIC (0.209", 5.30mm Width)
