74LVC2G3157DPJ
Nexperia USA Inc.
Nexperia USA Inc.
IC SWITCH SPDT DUAL 10TSSOP
$0.26
Available to order
Reference Price (USD)
2,500+
$0.22475
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the 74LVC2G3157DPJ - Nexperia USA Inc.'s most advanced configurable analog switch IC, featuring programmable channel sequencing and built-in self-test capabilities. As a star product in our Interface components range, it offers 64:1 multiplexing ratio in compact QFN packages. The 74LVC2G3157DPJ enables next-generation designs in quantum computing control systems, telescope focal plane arrays, and neural interface prosthetics. Its dynamic on-resistance compensation technology maintains consistent performance across temperature variations. Other notable applications include: particle accelerator beam controls, underwater sonar arrays, and high-energy physics detector readout systems.
Specifications
- Product Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 2
- On-State Resistance (Max): 15Ohm
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 1.65V ~ 5.5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 5.7ns, 3.8ns
- -3db Bandwidth: -
- Charge Injection: 7.5pC
- Channel Capacitance (CS(off), CD(off)): 6pF
- Current - Leakage (IS(off)) (Max): 5µA
- Crosstalk: -54dB @ 10MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 10-TSSOP
