852-80-030-30-001101

Preci-Dip

Manufacturer

Preci-Dip

Description:

CONN HEADER SMD 30POS 1.27MM

Datasheet:

852-80-030-30-001101 Datasheet

$4.95

Available to order

Reference Price (USD)

200+

$3.64770

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Choose the 852-80-030-30-001101 rectangular connector header from Preci-Dip for superior male pin interconnections. These headers are engineered for high-density applications, offering excellent conductivity and mechanical stability. Common uses include server racks, test equipment, and marine electronics. Preci-Dip is committed to providing connectors that exceed industry expectations.

Specifications

Product Status: Active
Connector Type: Header
Contact Type: Male Pin
Pitch - Mating: 0.050" (1.27mm)
Number of Positions: 30
Number of Rows: 2
Row Spacing - Mating: 0.050" (1.27mm)
Number of Positions Loaded: All
Style: Board to Board
Shrouding: Unshrouded
Mounting Type: Surface Mount
Termination: Solder
Fastening Type: Push-Pull
Contact Length - Mating: 0.118" (3.00mm)
Contact Length - Post: -
Overall Contact Length: -
Insulation Height: 0.075" (1.90mm)
Contact Shape: Circular
Contact Finish - Mating: Tin
Contact Finish Thickness - Mating: -
Contact Finish - Post: Tin
Contact Material: Brass
Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features: -
Operating Temperature: -55°C ~ 125°C
Ingress Protection: -
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Current Rating (Amps): 1A
Voltage Rating: 150VDC
