953371-3
TE Connectivity
TE Connectivity
16W MCP H RIGHT ANGLE HDR
$7.48
Available to order
Reference Price (USD)
1+
$7.48000
500+
$7.4052
1000+
$7.3304
1500+
$7.2556
2000+
$7.1808
2500+
$7.106
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 953371-3 by TE Connectivity is a premium rectangular connector header designed for male pin connections. Engineered for precision, these headers offer low insertion loss and high mating cycles. Perfect for high-density PCB applications, the 953371-3 supports various configurations to meet diverse needs. Its applications span across data communication, military equipment, and renewable energy systems. TE Connectivity ensures each connector meets rigorous quality standards for global compliance.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Tab
- Pitch - Mating: -
- Number of Positions: 16
- Number of Rows: 2
- Row Spacing - Mating: 0.236" (6.00mm)
- Number of Positions Loaded: All
- Style: Board to Cable/Wire
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole, Right Angle
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Length - Mating: 0.364" (9.25mm)
- Contact Length - Post: 0.139" (3.53mm)
- Overall Contact Length: -
- Insulation Height: 0.665" (16.90mm)
- Contact Shape: Rectangular
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Tin
- Contact Material: Brass
- Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled
- Features: Mounting Flange
- Operating Temperature: -40°C ~ 85°C
- Ingress Protection: -
- Material Flammability Rating: UL94 HB
- Insulation Color: Blue
- Current Rating (Amps): -
- Voltage Rating: 12V
