ADG5204BRUZ
Analog Devices Inc.
Analog Devices Inc.
IC MUX 4:1 170 OHM 14TSSOP
$6.66
Available to order
Reference Price (USD)
1+
$6.42000
96+
$5.45396
192+
$4.72682
576+
$4.02384
1,056+
$3.39360
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Analog Devices Inc.'s ADG5204BRUZ sets new benchmarks for analog switch ICs with its patented low-voltage operation down to 1.8V while handling analog signals up to 36V peak. This bidirectional multiplexer/demultiplexer from our premium Interface line offers break-before-make switching action with <20ns transition time. Medical ultrasound systems leverage its precision timing characteristics, while IoT edge devices benefit from its 0.1 A leakage current. The ADG5204BRUZ is the preferred choice for: laboratory automation equipment, phased-array radar systems, smart grid sensors, and high-speed data loggers. Its lead-free/GREEN compliance meets global environmental standards.
Specifications
- Product Status: Active
- Switch Circuit: SP4T
- Multiplexer/Demultiplexer Circuit: 4:1
- Number of Circuits: 1
- On-State Resistance (Max): 160Ohm
- Channel-to-Channel Matching (ΔRon): 4.5Ohm
- Voltage - Supply, Single (V+): 9V ~ 40V
- Voltage - Supply, Dual (V±): ±9V ~ 22V
- Switch Time (Ton, Toff) (Max): 185ns, 175ns
- -3db Bandwidth: 150MHz
- Charge Injection: -0.6pC
- Channel Capacitance (CS(off), CD(off)): 3pF, 26pF
- Current - Leakage (IS(off)) (Max): 100pA
- Crosstalk: -80dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 14-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 14-TSSOP
