ADG5401FBCPZ-RL7
Analog Devices Inc.
Analog Devices Inc.
60V OV PROTECTED HV SPSTX1 SWITC
$6.48
Available to order
Reference Price (USD)
1+
$6.48000
500+
$6.4152
1000+
$6.3504
1500+
$6.2856
2000+
$6.2208
2500+
$6.156
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The ADG5401FBCPZ-RL7 from Analog Devices Inc.'s Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The ADG5401FBCPZ-RL7 is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPST - NC
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 1
- On-State Resistance (Max): 6Ohm (Typ)
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 8V ~ 44V, ±5V ~ 22V
- Voltage - Supply, Dual (V±): 8V ~ 44V, ±5V ~ 22V
- Switch Time (Ton, Toff) (Max): 10.2µs, 360ns
- -3db Bandwidth: 395MHz
- Charge Injection: -230pC
- Channel Capacitance (CS(off), CD(off)): 9pF, 11pF
- Current - Leakage (IS(off)) (Max): 100pA (Typ)
- Crosstalk: -
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 10-WFDFN, CSP
- Supplier Device Package: 10-LFCSP (3x2)
