ADG774BRZ-REEL
Analog Devices Inc.
Analog Devices Inc.
IC MUX/DEMUX QUAD 2X1 16SOIC
$3.84
Available to order
Reference Price (USD)
1+
$3.84000
500+
$3.8016
1000+
$3.7632
1500+
$3.7248
2000+
$3.6864
2500+
$3.648
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The ADG774BRZ-REEL from Analog Devices Inc.'s Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The ADG774BRZ-REEL is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 4
- On-State Resistance (Max): 2.2Ohm (Typ)
- Channel-to-Channel Matching (ΔRon): 150mOhm
- Voltage - Supply, Single (V+): 3V ~ 5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 15ns, 8ns
- -3db Bandwidth: 240MHz
- Charge Injection: 10pC
- Channel Capacitance (CS(off), CD(off)): 10pF, 20pF
- Current - Leakage (IS(off)) (Max): 500pA
- Crosstalk: -75dB @ 10MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
