ADG824BCPZ-REEL7
Analog Devices Inc.
Analog Devices Inc.
IC SWITCH DUAL SPDT 10LFCSP
$2.81
Available to order
Reference Price (USD)
3,000+
$1.11807
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The ADG824BCPZ-REEL7 from Analog Devices Inc. is a high-performance Analog Switch/Multiplexer/Demultiplexer IC designed for precision signal routing applications. As part of our Interface - Analog Switches, Multiplexers, Demultiplexers category, this integrated circuit offers ultra-low on-resistance and minimal charge injection, ensuring signal integrity in demanding environments. These ICs feature wide bandwidth, low power consumption, and excellent channel-to-channel isolation. Typical applications include audio/video signal routing, automated test equipment, data acquisition systems, and communication infrastructure. The ADG824BCPZ-REEL7 is particularly suitable for medical imaging devices, industrial automation controls, and aerospace instrumentation where reliable signal switching is critical.
Specifications
- Product Status: Active
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 2
- On-State Resistance (Max): 800mOhm
- Channel-to-Channel Matching (ΔRon): 3mOhm
- Voltage - Supply, Single (V+): 1.65V ~ 3.6V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 9.5ns, 7.7ns
- -3db Bandwidth: 90MHz
- Charge Injection: 27pC
- Channel Capacitance (CS(off), CD(off)): 25pF
- Current - Leakage (IS(off)) (Max): 200pA (Typ)
- Crosstalk: -90dB @ 100kHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 10-UFQFN, CSP
- Supplier Device Package: 10-LFCSP-UQ (1.6x1.3)
