APT14M120S
Microchip Technology
Microchip Technology
MOSFET N-CH 1200V 14A D3PAK
$11.46
Available to order
Reference Price (USD)
1+
$11.46000
500+
$11.3454
1000+
$11.2308
1500+
$11.1162
2000+
$11.0016
2500+
$10.887
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the APT14M120S by Microchip Technology, a high-efficiency single MOSFET engineered for superior performance in the Discrete Semiconductor Products arena. Featuring low gate drive requirements and high switching frequency, this component is perfect for RF applications, power tools, and HVAC systems. The APT14M120S stands out in the Transistors - FETs, MOSFETs - Single category for its rugged design and consistent output. Choose quality, choose Microchip Technology.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 1200 V
- Current - Continuous Drain (Id) @ 25°C: 14A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 1.1Ohm @ 7A, 10V
- Vgs(th) (Max) @ Id: 5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 145 nC @ 10 V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 4765 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 625W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: D3PAK
- Package / Case: TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
