BAT54WT1G
onsemi
onsemi
DIODE SCHOTTKY 30V 200MA SC70-3
$0.22
Available to order
Reference Price (USD)
3,000+
$0.03723
6,000+
$0.03370
15,000+
$0.02947
30,000+
$0.02665
75,000+
$0.02383
150,000+
$0.02101
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the BAT54WT1G single rectifier diode by onsemi, a key component in the Diodes - Rectifiers - Single classification. This diode excels in providing stable and efficient rectification for circuits requiring precise voltage control. With its high surge current capability and low leakage, it is perfect for use in power management systems, LED drivers, and battery chargers. The BAT54WT1G is widely utilized in telecommunications, renewable energy systems, and medical devices, ensuring reliable operation under varying load conditions. Choose onsemi's BAT54WT1G for unmatched quality and performance in discrete semiconductor solutions.
Specifications
- Product Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Capacitance @ Vr, F: 10pF @ 1V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SC-70-3 (SOT323)
- Operating Temperature - Junction: -55°C ~ 125°C
