CBBJ159
Cinch Connectivity Solutions Trompeter
Cinch Connectivity Solutions Trompeter
CONN TRS JACK STR PCB
$98.62
Available to order
Reference Price (USD)
1+
$85.18000
10+
$80.17200
25+
$77.66680
50+
$76.63500
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for excellence, the CBBJ159 from Cinch Connectivity Solutions Trompeter sets new standards in Coaxial Connectors (RF) performance. These connectors utilize ultra-precision machining to achieve consistent 50 or 75 impedance matching across all mating cycles. The product line includes SMA, N-type, TNC, and BNC variants with options for straight, right-angle, and bulkhead mounting. Specialized versions feature phase-matched designs for critical array applications. Key industries served include: Satellite communication ground stations Electronic warfare systems High-speed data acquisition systems Microwave radio links. The CBBJ159 series stands out with its hybrid design combining the durability of metal connectors with the weight savings of composite materials, ideal for airborne electronic systems.
Specifications
- Product Status: Active
- Connector Style: TRS, Twinaxial/Triaxial
- Connector Type: Jack, Female Socket
- Contact Termination: Solder
- Shield Termination: Solder
- Impedance: -
- Mounting Type: Panel Mount, Through Hole
- Mounting Feature: Bulkhead - Front Side Nut
- Cable Group: -
- Fastening Type: Bayonet Lock
- Frequency - Max: 500 MHz
- Number of Ports: 1
- Features: Three Lug
- Housing Color: Silver
- Ingress Protection: -
- Center Contact Material: -
