CDR-03-GS

Adam Tech

Manufacturer

Adam Tech

Description:

HEADER VERT TH GOLD 3POS .1" SIN

Datasheet:

CDR-03-GS Datasheet

$0.23

Available to order

Reference Price (USD)

$0.23000

500+

$0.2277

1000+

$0.2254

1500+

$0.2231

2000+

$0.2208

2500+

$0.2185

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Upgrade your electronic designs with the CDR-03-GS rectangular connector header by Adam Tech. These male pin connectors provide a secure and efficient solution for PCB interconnections. Featuring a compact design and high conductivity, the CDR-03-GS ensures optimal signal transmission. Suitable for harsh environments, these headers are resistant to vibration and corrosion. Common uses include industrial automation, medical devices, and aerospace systems. Trust Adam Tech for connectors that deliver performance and reliability in every application.

Specifications

Product Status: Active
Connector Type: Header
Contact Type: Male Pin
Pitch - Mating: 0.100" (2.54mm)
Number of Positions: 3
Number of Rows: 1
Row Spacing - Mating: -
Number of Positions Loaded: All
Style: Board to Cable/Wire
Shrouding: Shrouded - 4 Wall
Mounting Type: Through Hole
Termination: Solder
Fastening Type: Latch Holder
Contact Length - Mating: -
Contact Length - Post: 0.132" (3.35mm)
Overall Contact Length: 0.492" (12.50mm)
Insulation Height: 0.453" (11.50mm)
Contact Shape: Square
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: Flash
Contact Finish - Post: Gold
Contact Material: Brass
Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled
Features: -
Operating Temperature: -40°C ~ 105°C
Ingress Protection: -
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Current Rating (Amps): 3A
Voltage Rating: 250VAC
