CXA1304-0000-000N0Y9235H
CreeLED, Inc.

CreeLED, Inc.
LED ARRAY XLAMP CXA1304 WHITE
$1.68
Available to order
Reference Price (USD)
100+
$1.69980
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The CXA1304-0000-000N0Y9235H by CreeLED, Inc. is a high-performance LED lighting solution in the Optoelectronics category, specifically LED Lighting - COBs, Engines, Modules, Strips. With excellent thermal stability and energy efficiency, this product is ideal for applications like UV curing, grow lights, and portable lighting. Trust CreeLED, Inc. to deliver superior LED products tailored to your requirements.
Specifications
- Product Status: Active
- Type: Chip On Board (COB)
- Color: White, Warm
- CCT (K): 3500K 2-Step MacAdam Ellipse
- Wavelength: -
- Configuration: Square
- Luminous Flux @ Current/Temperature: 297lm (286lm ~ 308lm)
- Current - Test: 100mA
- Temperature - Test: 85°C
- Voltage - Forward (Vf) (Typ): 37V
- Lumens/Watt @ Current - Test: 80 lm/W
- Current - Max: 250mA
- CRI (Color Rendering Index): 93
- Viewing Angle: 115°
- Features: -
- Size / Dimension: 13.35mm L x 13.35mm W
- Height: 1.70mm
- Light Emitting Surface (LES): 6.00mm Dia
- Lens Type: Flat
