DDTA114ECAQ-13-F
Diodes Incorporated
Diodes Incorporated
PREBIAS TRANSISTOR SOT23 T&R 10K
$0.03
Available to order
Reference Price (USD)
1+
$0.03081
500+
$0.0305019
1000+
$0.0301938
1500+
$0.0298857
2000+
$0.0295776
2500+
$0.0292695
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your PCB layout with Diodes Incorporated's space-saving DDTA114ECAQ-13-F. This pre-configured bipolar transistor eliminates external biasing components while delivering 250mW power dissipation. Applications span from smart home appliances to automotive lighting systems. Diodes Incorporated combines 20+ years of semiconductor expertise with cutting-edge silicon technology in this robust solution.
Specifications
- Product Status: Active
- Transistor Type: PNP - Pre-Biased + Diode
- Current - Collector (Ic) (Max): 100 mA
- Voltage - Collector Emitter Breakdown (Max): 50 V
- Resistor - Base (R1): 10 kOhms
- Resistor - Emitter Base (R2): 10 kOhms
- DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 5mA, 5V
- Vce Saturation (Max) @ Ib, Ic: 300mV @ 500µA, 10mA
- Current - Collector Cutoff (Max): 500nA
- Frequency - Transition: 250 MHz
- Power - Max: 200 mW
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3
