DG509BEJ-E3
Vishay Siliconix
Vishay Siliconix
IC MUX ANA DUAL 8/4CH 16DIP
$5.01
Available to order
Reference Price (USD)
1+
$4.11000
10+
$3.68900
25+
$3.48760
100+
$3.02250
250+
$2.86752
500+
$2.57300
1,000+
$2.17000
2,500+
$2.06150
5,000+
$1.98400
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Vishay Siliconix's DG509BEJ-E3 sets new benchmarks for analog switch ICs with its patented low-voltage operation down to 1.8V while handling analog signals up to 36V peak. This bidirectional multiplexer/demultiplexer from our premium Interface line offers break-before-make switching action with <20ns transition time. Medical ultrasound systems leverage its precision timing characteristics, while IoT edge devices benefit from its 0.1 A leakage current. The DG509BEJ-E3 is the preferred choice for: laboratory automation equipment, phased-array radar systems, smart grid sensors, and high-speed data loggers. Its lead-free/GREEN compliance meets global environmental standards.
Specifications
- Product Status: Active
- Switch Circuit: SP4T
- Multiplexer/Demultiplexer Circuit: 4:1
- Number of Circuits: 2
- On-State Resistance (Max): 380Ohm
- Channel-to-Channel Matching (ΔRon): 10Ohm
- Voltage - Supply, Single (V+): 12V
- Voltage - Supply, Dual (V±): ±5V ~ 20V
- Switch Time (Ton, Toff) (Max): 250ns, 240ns
- -3db Bandwidth: 250MHz
- Charge Injection: 2pC
- Channel Capacitance (CS(off), CD(off)): 3pF, 8pF
- Current - Leakage (IS(off)) (Max): 1nA
- Crosstalk: -88dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-PDIP
