DG9424EDN-T1-GE4
Vishay Siliconix
Vishay Siliconix
ANALOG SWITCH QUAD SPST 16-QFN
$3.07
Available to order
Reference Price (USD)
1+
$3.07000
500+
$3.0393
1000+
$3.0086
1500+
$2.9779
2000+
$2.9472
2500+
$2.9165
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The DG9424EDN-T1-GE4 from Vishay Siliconix's Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The DG9424EDN-T1-GE4 is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPST - NC
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- On-State Resistance (Max): 3Ohm
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 3V ~ 16V
- Voltage - Supply, Dual (V±): ±3V ~ 8V
- Switch Time (Ton, Toff) (Max): 51ns, 35ns
- -3db Bandwidth: -
- Charge Injection: 38pC
- Channel Capacitance (CS(off), CD(off)): 49pF, 37pF
- Current - Leakage (IS(off)) (Max): 1nA
- Crosstalk: -77dB @ 1MHz
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 16-VQFN Exposed Pad
- Supplier Device Package: 16-QFN (4x4)
