DMC1229UFDB-13
Diodes Incorporated
Diodes Incorporated
MOSFET N/P-CH 12V U-DFN2020-6
$0.16
Available to order
Reference Price (USD)
10,000+
$0.17490
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your electronic designs with the DMC1229UFDB-13 by Diodes Incorporated, a standout in the Discrete Semiconductor Products category. Specifically designed as a Transistors - FETs, MOSFETs - Arrays solution, this component excels in high-frequency applications with its low on-resistance and fast switching capabilities. Perfect for use in power supplies, motor control, and LED lighting systems, the DMC1229UFDB-13 ensures energy efficiency and robust performance. Diodes Incorporated's commitment to quality makes this MOSFET array a top choice for engineers and designers worldwide.
Specifications
- Product Status: Active
- FET Type: N and P-Channel
- FET Feature: Logic Level Gate
- Drain to Source Voltage (Vdss): 12V
- Current - Continuous Drain (Id) @ 25°C: 5.6A, 3.8A
- Rds On (Max) @ Id, Vgs: 29mOhm @ 5A, 4.5V
- Vgs(th) (Max) @ Id: 1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 19.6nC @ 8V
- Input Capacitance (Ciss) (Max) @ Vds: 914pF @ 6V
- Power - Max: 1.4W
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 6-UDFN Exposed Pad
- Supplier Device Package: U-DFN2020-6 (Type B)
