DMC3060LVTQ-7
Diodes Incorporated
Diodes Incorporated
MOSFET BVDSS: 25V~30V TSOT26 T&R
$0.17
Available to order
Reference Price (USD)
1+
$0.16726
500+
$0.1655874
1000+
$0.1639148
1500+
$0.1622422
2000+
$0.1605696
2500+
$0.158897
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the high-performance DMC3060LVTQ-7 from Diodes Incorporated, a premium addition to our Discrete Semiconductor Products collection. This Transistors - FETs, MOSFETs - Arrays component is engineered for efficiency and reliability, offering exceptional switching speeds and low power consumption. Ideal for power management and amplification circuits, this MOSFET array ensures minimal heat generation and superior durability. Whether you're designing industrial automation systems, automotive electronics, or consumer gadgets, the DMC3060LVTQ-7 delivers unmatched performance. Trust Diodes Incorporated's cutting-edge technology to meet your demanding application needs.
Specifications
- Product Status: Active
- FET Type: N and P-Channel
- FET Feature: Standard
- Drain to Source Voltage (Vdss): 30V
- Current - Continuous Drain (Id) @ 25°C: 3.6A (Ta), 2.8A (Ta)
- Rds On (Max) @ Id, Vgs: 60mOhm @ 3.1A, 10V, 95mOhm @ 2.7A, 10V
- Vgs(th) (Max) @ Id: 1.8V @ 250µA, 2.1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 11.3nC @ 10V, 8.6nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds: 395pF @ 15V, 324pF @ 15V
- Power - Max: 830mW (Ta)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: SOT-23-6 Thin, TSOT-23-6
- Supplier Device Package: TSOT-26
