DME-15-S-P-SQ
Adam Tech
Adam Tech
CONN HEADER VERT 15POS 6.35MM
$1.42
Available to order
Reference Price (USD)
1+
$1.35000
10+
$1.22500
100+
$1.05000
500+
$0.87500
1,000+
$0.75000
5,000+
$0.66500
10,000+
$0.65000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The DME-15-S-P-SQ male pin header by Adam Tech offers a dependable solution for rectangular connectors. Designed for easy integration, these headers ensure consistent connectivity in demanding environments. Features include high-temperature resistance and superior contact stability. Applications range from industrial machinery to smart home systems. Choose Adam Tech for connectors that combine innovation with durability.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.250" (6.35mm)
- Number of Positions: 15
- Number of Rows: 3
- Row Spacing - Mating: 0.250" (6.35mm)
- Number of Positions Loaded: All
- Style: Board to Cable/Wire
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Locking Ramp
- Contact Length - Mating: -
- Contact Length - Post: 0.177" (4.50mm)
- Overall Contact Length: -
- Insulation Height: 0.550" (13.97mm)
- Contact Shape: Circular
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Tin
- Contact Material: -
- Insulation Material: Polyamide (PA66), Nylon 6/6
- Features: Polarizing Key
- Operating Temperature: -25°C ~ 85°C
- Ingress Protection: -
- Material Flammability Rating: UL94 V-2
- Insulation Color: Natural
- Current Rating (Amps): 13A
- Voltage Rating: 600VAC
