DWM-40-01-G-D-200
Samtec Inc.
Samtec Inc.
CONN HDR 80POS 0.05 STACK T/H
$17.00
Available to order
Reference Price (USD)
1+
$10.17000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The DWM-40-01-G-D-200 from Samtec Inc. is a dependable solution for board-to-board connections, offering superior spacing and stacking capabilities. With excellent signal integrity and durability, these connectors are perfect for high-frequency applications. They are widely used in telecommunications, test & measurement equipment, and audio-visual systems. For example, the DWM-40-01-G-D-200 is often integrated into 5G base stations, oscilloscopes, and professional audio mixers.
Specifications
- Product Status: Active
- Number of Positions: 80
- Pitch: 0.050" (1.27mm)
- Number of Rows: 2
- Row Spacing: 0.100" (2.54mm)
- Length - Overall Pin: 0.450" (11.430mm)
- Length - Post (Mating): 0.130" (3.302mm)
- Length - Stack Height: 0.200" (5.080mm)
- Length - Tail: 0.120" (3.048mm)
- Mounting Type: Through Hole
- Termination: Solder
- Contact Finish - Post (Mating): Gold
- Contact Finish Thickness - Post (Mating): 10.0µin (0.25µm)
- Color: Black
