ED504S_L2_00001
Panjit International Inc.
Panjit International Inc.
SUPERFAST RECOVERY RECTIFIERS
$0.81
Available to order
Reference Price (USD)
1+
$0.81000
500+
$0.8019
1000+
$0.7938
1500+
$0.7857
2000+
$0.7776
2500+
$0.7695
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your electronic systems with the ED504S_L2_00001 single rectifier diode by Panjit International Inc.. As a vital component in the Discrete Semiconductor Products range, this diode offers superior rectification with minimal power loss. Its high-temperature tolerance and fast switching make it ideal for use in electric vehicles, industrial automation, and renewable energy systems. The ED504S_L2_00001 is also a preferred choice for consumer electronics, including TVs and audio equipment, where efficiency and reliability are paramount. Choose Panjit International Inc.'s ED504S_L2_00001 for advanced semiconductor solutions.
Specifications
- Product Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 400 V
- Current - Average Rectified (Io): 5A
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 35 ns
- Current - Reverse Leakage @ Vr: 1 µA @ 400 V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: TO-252
- Operating Temperature - Junction: -55°C ~ 150°C
