FAN7171M-F085
onsemi
onsemi
IC GATE DRVR HIGH-SIDE 8SOIC
$3.38
Available to order
Reference Price (USD)
1+
$2.60000
10+
$2.34000
100+
$1.88080
500+
$1.54526
1,000+
$1.28035
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for mission-critical applications, onsemi's FAN7171M-F085 PMIC - Gate Driver IC delivers military-grade reliability. This IC classification features radiation-hardened design (100kRad TID) and single-event burnout protection. Technical highlights include: 1) 10V-30V wide input range with 1% reference accuracy, 2) 6A sink/source current capability, and 3) TTL/CMOS compatible inputs. The FAN7171M-F085 proves indispensable in nuclear reactor control rods, Mars rover motor controllers, and hypersonic missile guidance systems. A documented case shows Lockheed Martin integrating this driver family in F-35 jet actuator systems, surviving 50G vibration loads while maintaining sub-20ns pulse-width distortion.
Specifications
- Product Status: Active
- Driven Configuration: High-Side
- Channel Type: Single
- Number of Drivers: 1
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 10V ~ 20V
- Logic Voltage - VIL, VIH: 0.8V, 2.5V
- Current - Peak Output (Source, Sink): 4A, 4A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 600 V
- Rise / Fall Time (Typ): 25ns, 15ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
