FAN7390M1X
onsemi
onsemi
IC GATE DRVR HALF-BRIDGE 14SOP
$2.87
Available to order
Reference Price (USD)
1+
$2.87000
500+
$2.8413
1000+
$2.8126
1500+
$2.7839
2000+
$2.7552
2500+
$2.7265
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FAN7390M1X from onsemi redefines compact power management as a space-optimized PMIC - Gate Driver IC. Measuring just 3x3mm QFN, this classification achieves 5kV reinforced isolation through innovative transformer coupling technology. Signature features are: 1) 50% lower quiescent current than industry average, 2) 3.3V/5V logic level translation, and 3) Lead-free/RoHS 3.0 compliance. Consumer electronics particularly benefit in wireless charging pads (Qi 1.3 standard), drone ESC modules, and VR headset power circuits. Real-world testing demonstrates the FAN7390M1X enabling 95W USB-PD adapters at 30W/in power density - a key enabler for Apple's MagSafe ecosystem.
Specifications
- Product Status: Not For New Designs
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 10V ~ 22V
- Logic Voltage - VIL, VIH: 1.2V, 2.5V
- Current - Peak Output (Source, Sink): 4.5A, 4.5A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 600 V
- Rise / Fall Time (Typ): 25ns, 20ns
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 14-SOP
