IVS1-3Q0-2L0-2W0-2W0-F0-A

Specifications

• Product Status: Active
• Type: Enclosed
• Number of Outputs: 3
• Voltage - Input: 85 ~ 264 VAC, 120 ~ 300 VDC
• Voltage - Output 1: 24V
• Voltage - Output 2: 12V
• Voltage - Output 3: 48V
• Voltage - Output 4: -
• Voltage - Output 5: -
• Voltage - Output 6: -
• Current - Output 1: 30 A
• Current - Output 2: 30 A
• Current - Output 3: 15 A
• Current - Output 4: -
• Current - Output 5: -
• Current - Output 6: -
• Power (Watts): 1800W
• Applications: ITE (Commercial), Medical
• Voltage - Isolation: 2 kV
• Efficiency: 85%
• Operating Temperature: -40°C ~ 70°C (With Derating)
• Features: Adjustable Output, I²C Interface, PFC, Remote Sense, Universal Input
• Mounting Type: Chassis Mount
• Size / Dimension: 11.00" L x 5.00" W x 5.00" H (279.4mm x 127.0mm x 127.0mm)
• Approval Agency: CB, CE, CSA, UL
• Standard Number: -
