JM54AC20BCA
National Semiconductor
National Semiconductor
IC GATE NAND 2CH 4-INP 14CERDIP
$8.87
Available to order
Reference Price (USD)
1+
$8.87000
500+
$8.7813
1000+
$8.6926
1500+
$8.6039
2000+
$8.5152
2500+
$8.4265
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The JM54AC20BCA from National Semiconductor delivers exceptional value in the Logic - Gates and Inverters market segment. This surface-mount IC combines multiple universal logic gates with optimized power-speed performance ratios. Key benefits include latch-up immunity exceeding 500mA and input leakage current below 1 A. Design engineers implement this component in power management systems, digital control circuits, and signal processing applications. Specific use cases include solar inverter controls, elevator logic boards, and industrial sensor networks. The JM54AC20BCA's compatibility with automated pick-and-place manufacturing processes makes it an economical choice for high-volume production runs across consumer and industrial sectors.
Specifications
- Product Status: Active
- Logic Type: NAND Gate
- Number of Circuits: 2
- Number of Inputs: 4
- Features: -
- Voltage - Supply: 2V ~ 6V
- Current - Quiescent (Max): 40 µA
- Current - Output High, Low: 24mA, 24mA
- Logic Level - Low: 0.9V ~ 1.65V
- Logic Level - High: 2.1V ~ 3.85V
- Max Propagation Delay @ V, Max CL: 8.5ns @ 5V, 50pF
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Through Hole
- Supplier Device Package: 14-CERDIP
- Package / Case: 14-CDIP (0.300", 7.62mm)
