LF2136BTR
IXYS Integrated Circuits Division
IXYS Integrated Circuits Division
GATE DRIVER HALF BRIDGE 3P 0.12A
$3.69
Available to order
Reference Price (USD)
1+
$3.69000
500+
$3.6531
1000+
$3.6162
1500+
$3.5793
2000+
$3.5424
2500+
$3.5055
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
IXYS Integrated Circuits Division's LF2136BTR represents a breakthrough in multi-chip PMIC - Gate Driver ICs with integrated current sensing. This all-in-one solution combines: 1) 16-bit shunt monitor, 2) Isolated 2.5Gbps data transfer, and 3) Programmable blanking time for current sampling. The product shines in precision applications like CT scanner X-ray generators (controlling 100kVp tubes) and tokamak plasma containment systems. Field data from ITER fusion reactor shows the LF2136BTR driver family maintaining 0.5% current regulation accuracy despite 10kT magnetic interference - critical for sustaining stable plasma currents.
Specifications
- Product Status: Active
- Driven Configuration: Half-Bridge
- Channel Type: 3-Phase
- Number of Drivers: 3
- Gate Type: IGBT, N-Channel MOSFET
- Voltage - Supply: 10V ~ 20V
- Logic Voltage - VIL, VIH: 0.8V, 2.4V
- Current - Peak Output (Source, Sink): 200mA, 350mA
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 600 V
- Rise / Fall Time (Typ): 90ns, 35ns
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 28-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 28-SOIC
