LM2940IMP-5.0/NOPB

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LINEAR 5V 1A SOT223-4

Datasheet:

LM2940IMP-5.0/NOPB Datasheet

$1.82

Available to order

Reference Price (USD)

$1.82000

500+

$1.8018

1000+

$1.7836

1500+

$1.7654

2000+

$1.7472

2500+

$1.729

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Discover the LM2940IMP-5.0/NOPB linear voltage regulator IC by Texas Instruments, a standout product in our PMIC - Voltage Regulators - Linear category. This IC provides precise voltage regulation with ultra-low noise output, making it perfect for analog and RF circuits. The device features excellent PSRR (Power Supply Rejection Ratio) performance and comes in various package options to suit different design requirements. Linear regulators such as this LM2940IMP-5.0/NOPB model are extensively used in consumer electronics (smartphones, tablets), IoT devices, and aerospace applications where consistent voltage without switching noise is essential. Its robust design ensures reliable operation in harsh environments with wide temperature ranges.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 26V
Voltage - Output (Min/Fixed): 5V
Voltage - Output (Max): -
Voltage Dropout (Max): 1V @ 1A
Current - Output: 1A
Current - Quiescent (Iq): 10 mA
Current - Supply (Max): 15 mA
PSRR: 64dB (120Hz)
Control Features: -
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Operating Temperature: -40°C ~ 85°C
Mounting Type: Surface Mount
Package / Case: TO-261-4, TO-261AA
Supplier Device Package: SOT-223-4
