LM2940SX-9.0/NOPB

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LIN 9V 1A DDPAK/TO263-3

Datasheet:

LM2940SX-9.0/NOPB Datasheet

$2.51

Available to order

Reference Price (USD)

$2.51000

500+

$2.4849

1000+

$2.4598

1500+

$2.4347

2000+

$2.4096

2500+

$2.3845

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The LM2940SX-9.0/NOPB from Texas Instruments is a high-performance PMIC - Voltage Regulators - Linear IC that ensures stable and efficient power delivery for your electronic devices. This IC features low quiescent current, high accuracy, and robust thermal performance, making it a versatile solution for various applications. Whether you're designing for consumer electronics or industrial systems, the LM2940SX-9.0/NOPB provides the reliability you need. As a member of the PMIC - Voltage Regulators - Linear family, the LM2940SX-9.0/NOPB excels in delivering consistent voltage outputs with minimal deviation. Its advanced design includes protection features such as over-current and over-temperature shutdown, enhancing its durability and safety. These qualities make it a preferred choice for critical applications. The LM2940SX-9.0/NOPB is widely used in sectors like healthcare, automotive, and consumer electronics. For instance, it powers portable medical devices, in-car entertainment systems, and smart appliances. Its ability to deliver clean and stable power ensures the longevity and efficiency of your electronic designs.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 26V
Voltage - Output (Min/Fixed): 9V
Voltage - Output (Max): -
Voltage Dropout (Max): 1V @ 1A
Current - Output: 1A
Current - Quiescent (Iq): 10 mA
Current - Supply (Max): 15 mA
PSRR: 64dB (120Hz)
Control Features: -
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
Supplier Device Package: DDPAK/TO-263-3
