LM5113TME/NOPB
Texas Instruments
Texas Instruments
IC GATE DRVR HALF-BRIDGE 12DSBGA
$5.72
Available to order
Reference Price (USD)
250+
$3.15424
500+
$2.83030
1,250+
$2.38700
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Texas Instruments's LM5113TME/NOPB establishes new standards for automotive PMIC - Gate Driver ICs with ASIL-D functional safety certification. This IC classification incorporates: 1) Redundant fault detection circuits, 2) On-chip LDO for auxiliary power, and 3) ISO 26262-compliant failure modes. Automotive applications range from 48V mild-hybrid BSG systems to steer-by-wire and brake-by-wire architectures. Benchmark tests show the LM5113TME/NOPB reducing ECU wake-up time by 200ms in Volkswagen's MEB platform, while preventing latch-up during load-dump transients up to 45V. The driver also enables <1 A standby current for always-on ADAS modules.
Specifications
- Product Status: Not For New Designs
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 4.5V ~ 5.5V
- Logic Voltage - VIL, VIH: 1.76V, 1.89V
- Current - Peak Output (Source, Sink): 1.2A, 5A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 107 V
- Rise / Fall Time (Typ): 7ns, 1.5ns
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 12-WFBGA, DSBGA
- Supplier Device Package: 12-DSBGA
