LP2985AIM5-3.6/NOPB
Texas Instruments
Texas Instruments
IC REG LINEAR 3.6V 150MA SOT23-5
$1.15
Available to order
Reference Price (USD)
1+
$1.15000
500+
$1.1385
1000+
$1.127
1500+
$1.1155
2000+
$1.104
2500+
$1.0925
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The LP2985AIM5-3.6/NOPB from Texas Instruments is a high-performance linear voltage regulator IC designed for precision power management applications. As part of our PMIC - Voltage Regulators - Linear collection, this component offers exceptional voltage regulation with low dropout characteristics. Featuring thermal shutdown protection and current limiting, this IC maintains stable output voltage even under varying load conditions. These linear regulators are ideal for noise-sensitive applications requiring clean power delivery, such as medical devices, audio equipment, and precision measurement instruments. Typical implementations include power conditioning for microcontroller systems, battery-powered devices, and as post-regulators for switching power supplies.
Specifications
- Product Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 16V
- Voltage - Output (Min/Fixed): 3.6V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.58V @ 150mA
- Current - Output: 150mA
- Current - Quiescent (Iq): 95 µA
- Current - Supply (Max): 2.5 mA
- PSRR: 45dB (1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Short Circuit
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
