M80-4054205
Harwin Inc.
Harwin Inc.
21+21 WAY FEMALE PC TAIL 3MM
$29.04
Available to order
Reference Price (USD)
1+
$29.03560
500+
$28.745244
1000+
$28.454888
1500+
$28.164532
2000+
$27.874176
2500+
$27.58382
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover high-quality M80-4054205 Harwin Inc. Rectangular Connectors - Headers, Receptacles, and Female Sockets designed for reliable and secure connections in various electronic applications. These connectors feature durable construction, precise pin alignment, and excellent conductivity, ensuring optimal performance in demanding environments. Ideal for industrial automation, telecommunications, and consumer electronics, our rectangular connectors provide a robust solution for your interconnection needs. Examples include PCB mounting, wire-to-board connections, and modular device interfaces. Trust Harwin Inc. for precision-engineered connectors that meet global standards.
Specifications
- Product Status: Active
- Connector Type: Receptacle
- Contact Type: Female Socket
- Style: Board to Board or Cable
- Number of Positions: 42
- Number of Positions Loaded: All
- Pitch - Mating: 0.079" (2.00mm)
- Number of Rows: 2
- Row Spacing - Mating: 0.079" (2.00mm)
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Screw Lock
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 12.0µin (0.30µm)
- Insulation Color: Black
- Insulation Height: 0.204" (5.17mm)
- Contact Length - Post: 0.118" (3.00mm)
- Operating Temperature: -55°C ~ 125°C
- Material Flammability Rating: UL94 V-0
- Contact Finish - Post: Gold
- Mated Stacking Heights: 7.3mm, 7.55mm
- Ingress Protection: -
- Features: Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
- Current Rating (Amps): -
- Voltage Rating: 800V
