MAX4731EUA+
Analog Devices Inc./Maxim Integrated
Analog Devices Inc./Maxim Integrated
IC SWITCH DUAL SPST 8UMAX
$1.50
Available to order
Reference Price (USD)
400+
$0.95200
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The MAX4731EUA+ from Analog Devices Inc./Maxim Integrated's Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The MAX4731EUA+ is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPST - NO
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 2
- On-State Resistance (Max): 25Ohm
- Channel-to-Channel Matching (ΔRon): 200mOhm
- Voltage - Supply, Single (V+): 2V ~ 11V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 85ns, 45ns
- -3db Bandwidth: 300MHz
- Charge Injection: 7.5pC
- Channel Capacitance (CS(off), CD(off)): 20pF, 20pF
- Current - Leakage (IS(off)) (Max): 100pA
- Crosstalk: -108dB @ 1MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 8-uMAX/uSOP
