MBR1090DC_R2_00001
Panjit International Inc.
Panjit International Inc.
D PAK SURFACE MOUNT SCHOTTKY BAR
$0.99
Available to order
Reference Price (USD)
1+
$0.99000
500+
$0.9801
1000+
$0.9702
1500+
$0.9603
2000+
$0.9504
2500+
$0.9405
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The MBR1090DC_R2_00001 from Panjit International Inc. sets new benchmarks in the Discrete Semiconductor Products market. This rectifier array incorporates advanced epitaxial growth technology for superior reverse recovery characteristics. Perfect for high-efficiency adapters, induction heating, and plasma cutting equipment, it offers outstanding thermal cycling performance. Panjit International Inc.'s rigorous quality control ensures the MBR1090DC_R2_00001 maintains consistent parameters across production batches for design-in reliability.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 90 V
- Current - Average Rectified (Io) (per Diode): 10A
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 50 µA @ 90 V
- Operating Temperature - Junction: -65°C ~ 175°C
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: TO-263
