MPTS1206L110R
Meritek
Meritek
PTC RESET FUSE 8V 1.1A 1206
$0.15
Available to order
Reference Price (USD)
1+
$0.15010
500+
$0.148599
1000+
$0.147098
1500+
$0.145597
2000+
$0.144096
2500+
$0.142595
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the MPTS1206L110R PTC resettable fuse by Meritek, a top-tier solution for circuit protection. These fuses automatically reset after a fault, providing continuous protection without manual intervention. The MPTS1206L110R is engineered to handle high surge currents and offers stable performance across a wide temperature range. Its robust construction ensures reliability in applications such as power supplies, battery packs, and telecommunications equipment. By choosing the MPTS1206L110R, you're investing in a fuse that combines innovation, safety, and efficiency for all your circuit protection needs.
Specifications
- Product Status: Active
- Type: Polymeric
- Voltage - Max: 8V
- Current - Max: 100 A
- Current - Hold (Ih) (Max): 1.1 A
- Current - Trip (It): 2.2 A
- Time to Trip: 300 ms
- Resistance - Initial (Ri) (Min): 40 mOhms
- Resistance - Post Trip (R1) (Max): 180 mOhms
- Resistance - 25°C (Typ): -
- Operating Temperature: -40°C ~ 85°C
- Ratings: -
- Mounting Type: Surface Mount
- Package / Case: 1206 (3216 Metric), Concave
- Size / Dimension: 0.128" L x 0.065" W (3.25mm x 1.65mm)
- Height - Seated (Max): -
- Thickness (Max): 0.039" (1.00mm)
- Lead Spacing: -
