MSCSM120AM08CT3AG
Microchip Technology
Microchip Technology
PM-MOSFET-SIC-SBD~-SP3F
$529.47
Available to order
Reference Price (USD)
1+
$529.47000
500+
$524.1753
1000+
$518.8806
1500+
$513.5859
2000+
$508.2912
2500+
$502.9965
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The MSCSM120AM08CT3AG by Microchip Technology is a high-performance component within the Discrete Semiconductor Products category. Designed as part of the Transistors - FETs, MOSFETs - Arrays series, it offers exceptional durability and efficiency for power-sensitive applications. From medical equipment to aerospace technology, the MSCSM120AM08CT3AG provides reliable operation under stringent conditions. Microchip Technology's innovative approach ensures this MOSFET array meets the needs of modern electronics.
Specifications
- Product Status: Active
- FET Type: 2 N Channel (Phase Leg)
- FET Feature: Silicon Carbide (SiC)
- Drain to Source Voltage (Vdss): 1200V (1.2kV)
- Current - Continuous Drain (Id) @ 25°C: 337A (Tc)
- Rds On (Max) @ Id, Vgs: 7.8mOhm @ 160A, 20V
- Vgs(th) (Max) @ Id: 2.8V @ 4mA
- Gate Charge (Qg) (Max) @ Vgs: 928nC @ 20V
- Input Capacitance (Ciss) (Max) @ Vds: 12.08pF @ 1000V
- Power - Max: 1.409kW (Tc)
- Operating Temperature: -40°C ~ 175°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Module
- Supplier Device Package: SP3F
