NC7WZ38K8X
onsemi
onsemi
IC GATE NAND OD 2CH 2-INP US8
$0.59
Available to order
Reference Price (USD)
3,000+
$0.14539
6,000+
$0.13601
15,000+
$0.12663
30,000+
$0.12006
75,000+
$0.11725
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Experience reliable digital logic performance with onsemi's NC7WZ38K8X, a key component in our Logic - Gates and Inverters selection. This IC features buffered outputs for improved drive capability and reduced signal distortion. Technical highlights include 5ns maximum propagation delay and 24mA output drive at 5V. The NC7WZ38K8X serves critical functions in computer architecture, including address decoding, bus interfacing, and memory control. Real-world applications encompass point-of-sale terminals, industrial HMI panels, and automotive dashboard electronics. With its moisture sensitivity level (MSL) rating of 1, this component is suitable for demanding production environments and extended storage periods.
Specifications
- Product Status: Obsolete
- Logic Type: NAND Gate
- Number of Circuits: 2
- Number of Inputs: 2
- Features: Open Drain
- Voltage - Supply: 1.65V ~ 5.5V
- Current - Quiescent (Max): 1 µA
- Current - Output High, Low: -, 32mA
- Logic Level - Low: -
- Logic Level - High: -
- Max Propagation Delay @ V, Max CL: 3.4ns @ 5V, 50pF
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Supplier Device Package: US8
- Package / Case: 8-VFSOP (0.091", 2.30mm Width)
