NEVO+600M-2803-DK000

Specifications

• Product Status: Active
• Type: Open Frame
• Number of Outputs: 3
• Voltage - Input: 85 ~ 264 VAC, 120 ~ 300 VDC
• Voltage - Output 1: 24V
• Voltage - Output 2: 24V
• Voltage - Output 3: 12V
• Voltage - Output 4: -
• Voltage - Output 5: -
• Voltage - Output 6: -
• Current - Output 1: 7.5 A
• Current - Output 2: 3.13 A
• Current - Output 3: 15 A
• Current - Output 4: -
• Current - Output 5: -
• Current - Output 6: -
• Power (Watts): 450W
• Applications: Medical
• Voltage - Isolation: 4 kV
• Efficiency: 86%
• Operating Temperature: -20°C ~ 70°C
• Features: Adjustable Output, Load Sharing, Remote Sense, Universal Input
• Mounting Type: Chassis Mount
• Size / Dimension: 5.27" L x 3.06" W x 1.61" H (133.8mm x 77.7mm x 41.0mm)
• Approval Agency: CB, CE, CSA, UL
• Standard Number: 60601-1
