NJM2863F05-TE1
Nisshinbo Micro Devices Inc.
Nisshinbo Micro Devices Inc.
IC REG LINEAR 5V 100MA SOT23-5
$0.37
Available to order
Reference Price (USD)
1+
$0.36519
500+
$0.3615381
1000+
$0.3578862
1500+
$0.3542343
2000+
$0.3505824
2500+
$0.3469305
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The NJM2863F05-TE1 from Nisshinbo Micro Devices Inc. is a high-performance linear voltage regulator IC designed for precision power management applications. As part of our PMIC - Voltage Regulators - Linear collection, this component offers exceptional voltage regulation with low dropout characteristics. Featuring thermal shutdown protection and current limiting, this IC maintains stable output voltage even under varying load conditions. These linear regulators are ideal for noise-sensitive applications requiring clean power delivery, such as medical devices, audio equipment, and precision measurement instruments. Typical implementations include power conditioning for microcontroller systems, battery-powered devices, and as post-regulators for switching power supplies.
Specifications
- Product Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 14V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.1V @ 60mA
- Current - Output: 100mA
- Current - Quiescent (Iq): 180 µA
- Current - Supply (Max): -
- PSRR: 75dB (1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Short Circuit
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5 (MTP5)
