PC156HR-24-S-06-T-LF
Major League Electronics
Major League Electronics
.156 Header
$3.42
Available to order
Reference Price (USD)
1+
$3.42000
500+
$3.3858
1000+
$3.3516
1500+
$3.3174
2000+
$3.2832
2500+
$3.249
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the PC156HR-24-S-06-T-LF rectangular connector header from Major League Electronics, a top choice for male pin interconnections. These headers provide exceptional mechanical strength and electrical performance. With options for through-hole or surface mount, the PC156HR-24-S-06-T-LF adapts to different assembly processes. Ideal for use in automotive electronics, consumer gadgets, and IoT devices. Major League Electronics guarantees connectors that enhance your product's reliability and efficiency.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.156" (3.96mm)
- Number of Positions: 24
- Number of Rows: 1
- Row Spacing - Mating: -
- Number of Positions Loaded: All
- Style: Board to Board
- Shrouding: Unshrouded
- Mounting Type: Through Hole, Right Angle
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Length - Mating: 0.320" (8.13mm)
- Contact Length - Post: 0.175" (4.45mm)
- Overall Contact Length: -
- Insulation Height: 0.125" (3.18mm)
- Contact Shape: Square
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Tin
- Contact Material: Brass
- Insulation Material: Liquid Crystal Polymer (LCP)
- Features: -
- Operating Temperature: -55°C ~ 105°C
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Insulation Color: Black
- Current Rating (Amps): 7.9A
- Voltage Rating: -
