PD70FG80
SanRex Corporation
SanRex Corporation
THYRISTOR MODULE 800V 70A
$40.49
Available to order
Reference Price (USD)
1+
$40.49000
500+
$40.0851
1000+
$39.6802
1500+
$39.2753
2000+
$38.8704
2500+
$38.4655
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The PD70FG80 Thyristors - SCRs - Modules by SanRex Corporation are engineered for superior power control and efficiency. These discrete semiconductor products are widely used in applications requiring high surge current handling and fast switching, such as laser power supplies and plasma cutting equipment. With advanced thermal management and robust construction, these modules deliver reliable performance in extreme conditions. Trust SanRex Corporation for semiconductor solutions that combine cutting-edge technology with unmatched durability, ensuring your systems run smoothly and efficiently.
Specifications
- Product Status: Active
- Structure: Series Connection - SCR/Diode
- Number of SCRs, Diodes: 1 SCR, 1 Diode
- Voltage - Off State: 800 V
- Current - On State (It (AV)) (Max): 70 A
- Current - On State (It (RMS)) (Max): 110 A
- Voltage - Gate Trigger (Vgt) (Max): 3 V
- Current - Gate Trigger (Igt) (Max): 50 mA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 1460A, 1600A
- Current - Hold (Ih) (Max): -
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Module
