PL75-55
Cinch Connectivity Solutions Trompeter
Cinch Connectivity Solutions Trompeter
CONN TRB PLUG STR SOLDER
$40.91
Available to order
Reference Price (USD)
1+
$43.34000
10+
$39.59700
25+
$38.14200
50+
$36.67500
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The PL75-55 from Cinch Connectivity Solutions Trompeter represents the pinnacle of Coaxial Connectors (RF) innovation. This series incorporates temperature-compensated designs that maintain stable electrical characteristics across extreme thermal cycles. Featuring industry-leading return loss (>20dB typical) and insertion loss (<0.1dB per connection), these connectors are ideal for sensitive measurement applications. The product family includes field-installable, panel-mount, and PCB receptacle variants. Primary application areas: Military radar systems Quantum cascade lasers EMC test chambers Cellular base station radios. The PL75-55 variant offers unique angled cable exits that simplify routing in space-constrained equipment enclosures while maintaining impedance control.
Specifications
- Product Status: Active
- Connector Style: TRB, Twinaxial/Triaxial
- Connector Type: Plug, Male Pin (Concentric)
- Contact Termination: Solder
- Shield Termination: Wrench Clamp
- Impedance: Non-Constant
- Mounting Type: Free Hanging (In-Line)
- Mounting Feature: -
- Cable Group: Belden 89272
- Fastening Type: Bayonet Lock
- Frequency - Max: 500 MHz
- Number of Ports: 1
- Features: Three Lug
- Housing Color: Silver
- Ingress Protection: -
- Center Contact Material: Beryllium Copper
