R164286000
Radiall USA, Inc.
Radiall USA, Inc.
QN / STRAIGHT SQUARE FLANGE JACK
$17.91
Available to order
Reference Price (USD)
1+
$17.91000
500+
$17.7309
1000+
$17.5518
1500+
$17.3727
2000+
$17.1936
2500+
$17.0145
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The R164286000 from Radiall USA, Inc. represents the pinnacle of Coaxial Connectors (RF) innovation. This series incorporates temperature-compensated designs that maintain stable electrical characteristics across extreme thermal cycles. Featuring industry-leading return loss (>20dB typical) and insertion loss (<0.1dB per connection), these connectors are ideal for sensitive measurement applications. The product family includes field-installable, panel-mount, and PCB receptacle variants. Primary application areas: Military radar systems Quantum cascade lasers EMC test chambers Cellular base station radios. The R164286000 variant offers unique angled cable exits that simplify routing in space-constrained equipment enclosures while maintaining impedance control.
Specifications
- Product Status: Active
- Connector Style: QN
- Connector Type: Jack, Female Socket
- Contact Termination: Crimp
- Shield Termination: Crimp
- Impedance: 50Ohm
- Mounting Type: Panel Mount
- Mounting Feature: Flange
- Cable Group: RG-165, 213
- Fastening Type: Snap-On
- Frequency - Max: 6 GHz
- Number of Ports: 1
- Features: -
- Housing Color: Silver
- Ingress Protection: IP68 - Dust Tight, Waterproof
- Center Contact Material: Beryllium Copper
