RS2259XTSS16
Runic Technology
Runic Technology
IC SWITCH QUAD SPST 16TSSOP
$2.81
Available to order
Reference Price (USD)
1+
$2.81000
500+
$2.7819
1000+
$2.7538
1500+
$2.7257
2000+
$2.6976
2500+
$2.6695
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The RS2259XTSS16 from Runic Technology's Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The RS2259XTSS16 is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPST
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- On-State Resistance (Max): 1Ohm
- Channel-to-Channel Matching (ΔRon): 40mOhm (Typ)
- Voltage - Supply, Single (V+): 1.8V ~ 5.5V
- Voltage - Supply, Dual (V±): 1.8V ~ 5.5V
- Switch Time (Ton, Toff) (Max): 50ns (Typ), 15ns (Typ)
- -3db Bandwidth: 30MHz
- Charge Injection: -
- Channel Capacitance (CS(off), CD(off)): 80pF, 80pF
- Current - Leakage (IS(off)) (Max): 1µA
- Crosstalk: -
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
